7,300.00

SKU: GP-P750GM Categories: ,

Description

GIGABYTE P750GM 80 Plus Gold SMPS (GP-P750GM)

Wattage 750 Watt
Certification 80+ Gold
Modularity Fully Modular
PCIe Connector (6+2) 4
SATA Connector 8
Peripheral (4-pin) 3
Warranty 5 Years

Specifications

Model GP-P750GM
Type Intel Form Factor ATX 12V v2.31
PFC Active PFC (>0.9 typical)
Input Voltage 1‎00-240 Vac (full range)
Input Current 1‎2-6 A
Input Frequency 6‎0-50 Hz
Output Capacity 7‎50W
Dimension 1‎50 x 140 x 86 mm
Fan Type 1‎20mm Hydraulic Bearing ( HYB ) fan
80 PLUS Gold
Efficiency 9‎0% at typical load
MTBF >100,000 hours
Protection OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal 1‎00-500ms
Hold Up Time >16ms
Cable Type Flat, All black
Connectors ATX/MB 20+4 Pin x 1 : 610mm*1
CPU/EPS 4+4 Pin x 2 : 600mm*2
PCI-e 6+2 Pin x 4 : 600mm+150mm*2
SATA x 8 : 600mm+150mm+150mm+150mm*2 :
4 Pin Peripheral x 3 + 4-Pin floppy x 1 :
500mm+120mm+120mm+120mm *1
Warranty 5 Years
Note ***Features, Price and Specifications are subject to change without notice.
