  • Modular Design
  • High quality Japanese electrolytic capacitors
  • 120mm smart control fan
  • 80 Plus Bronze certified
  • Single 12V rail
  • Supports NVIDIA SLI / AMD CROSSFIRE
SKU: B700H Categories: ,

Description

PRODUCT SPECIFICATIONS

  • Model: B700H
  • Type: Intel Form Factor ATX 12V v2.31
  • PFC: Active PFC (>0.9 typical)
  • Input Voltage: 100-240 Vac (full range)
  • Input Current: 10A
  • Input Frequency: 47-63 Hz
  • Output Capacity: 700W
  • Dimension: D140 x W150 x H86mm
  • Fan Type: 120mm Double ball bearing fan
  • Efficiency: 85% at typical load
  • MTBF: >100,000 hours
  • Protection: OVP/OPP/SCP/UVP
  • Regulatory: CE/BSMI/EAC/TUV/FCC/UL/RCM/KCC/CCC
  • Connectors: MB 20 4 Pin x1
    CPU 4 4 Pin x1
    PCI-e 6 2 Pin x4
    SATA x7
    4Pin Peripheral x3
    4Pin Floopy x1
  • Cable Type: Black Flat Cables
