| Specification |
Details |
| Model Number |
ST24000NT002 |
| Capacity |
24TB |
| Form Factor |
3.5-inch |
| Interface |
SATA III 6 Gb/s (also supports 3.0 and 1.5 Gb/s) |
| Cache |
512MB |
| Spindle Speed |
7200 RPM |
| Recording Technology |
CMR (Conventional Magnetic Recording) |
| Drive Design |
Helium-filled |
| Max Sustained Transfer Rate |
285 MB/s |
| Workload Rate Limit |
550TB/year |
| MTBF (Mean Time Between Failures) |
2.5 million hours |
| Non-Recoverable Read Errors |
1 per 10^15 bits read |
| Power-On Hours per Year |
8,760 hours |
| Startup Current (12V) |
2.0 A |
| Idle Power Consumption |
6.3 W |
| Operating Power Consumption |
7.8 W |
| Standby/Sleep Power Consumption |
1.1 W |
| Voltage Requirements |
+12 V and +5 V |
| Operating Temperature (Ambient) |
5°C to 65°C |
| Non-Operating Temperature |
-40°C to 70°C |
| Vibration (Non-Operating) |
2.27 Gs (10Hz to 500Hz) |
| Shock (Operating) |
40 Gs (2ms) |
| Shock (Non-Operating) |
200 Gs (1ms and 2ms) |
| Acoustics (Idle/Seek) |
20 dBA / 26 dBA |
| Rotational Vibration Sensors |
Yes |
| Dimensions (H x W x D) |
26.11 mm x 101.85 mm x 146.99 mm |
| Weight |
685 g (1.512 lb) |
| Rescue Data Recovery Services |
3-Year included |
| Warranty |
5-Year limited warranty |
| NAS Optimization |
AgileArray technology with TLER, RV sensors, dual-plane balancing |
| Note** |
**Prices, Specifications & Features are subject to change without notice |
