Msi Mag B660M Mortar Wifi Lga1700 Matx Motherboard (Mag B660M Mortar Wifi)

20,400.00

Inclusive of all taxes

Model No : MAG B660M MORTAR WIFI DDR5
Buy Now

All over India Shipping

Competitive Pricing

Experts in pc building

product description

Description

MSI MAG B660M MORTAR WIFI LGA1700 MATX MOTHERBOARD (MAG B660M MORTAR WIFI)

  • Supports 12th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
  • Supports DDR5 Memory, up to 6200+(OC) MHz
  • Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
  • 2.5G LAN and Intel Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
  • Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs
  • Lightning USB 20G: Built-in USB 3.2 Gen 2×2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1
  • AUDIO BOOST: Reward your ears with studio grade sound quality
  • Multi-GPU: With Steel armor PCIe slots. Supports AMD Crossfire™
CPU (Max Support) i9
Socket 1700
Chipset Intel B660
DDR5 Memory 6200(OC)/ 6133(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Memory Channel Dual
DIMM Slots 4
Max Memory (GB) 128
PCI-E X16 2
PCI-E X1 1
SATAIII 6
M.2 Slot 2
RAID 0/1/5/10
LAN 1x Realtek® 8125BG 2.5G LAN
WIFI & Bluetooth Intel® Wi-Fi 6E module
USB 3.2 Ports (Front) 1(Gen 2, Type C), 2(Gen 1, Type A)
USB 3.2 Ports (Rear) 1(Gen 2×2, Type C), 3(Gen 2, Type A)
USB 2.0 Ports (Front) 4
USB 2.0 Ports (Rear) 4
Audio Ports (Rear) Realtek® ALC1200 Codec
Display Port 1
HDMI 1
DirectX 12
Form Factor MATX
Cross Fire Y
Operating System Support for Windows® 11 64-bit, Windows® 10 64-bit
Warranty 3 Years
Note** **Prices, Features & Specifications are subject to change without notice
