Description
Deepcool PX1200G 1200 Watt Fully modular Atx 3.0 80 Plus Gold Power Supply (R-PXC00G-FC0B-UK)
PX1200G
The DeepCool PX1200G is a newly designed power supply that meets the latest ATX 3.0 standard. With a dedicated 12VHPWR, 2 EPS, and 3 PCI-e ports, the PX1200G provides stable power for a wide range of components.
PAST, PRESENT,AND FUTURE
With the ability to provide three times the total GPU and twice the total system power for 0.1 ms, power spikes will never be an issue. The PX1200G will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.
PREMIUM QUALITY
Solid and reliable power is provided through the use of full Japanese 105C capacitors. Due to the high quality of the PSU build, the PX1200G will operate at altitudes up to 5000 meters above sea level.
RELIABLE STABILITY
Through the use of a dual main capacitor topology, the PX1200G can keep the hold-up time to ≥ 16ms under full load.
PCI-E 5.0 POWER PERFECTED
Equipped with the new PCI-e Gen 5.0 12VHPWR cable, the PX-G provides up to 600W for power hungry GPUS.
STATIC TO DYNAMIC
The PX1200G comes equipped with the option to switch into semi-fanless operation. In hybrid mode, the 135mm FDB fan will dynamically adjust out of its zero RPM state once the system load hits a certain threshold.
Specifications
Model | |
---|---|
Model | R-PXC00G-FC0B-UK |
Type | ATX12V V3.0 |
Spec | |
Product Dimensions | 150×160×86mm (W x L x H) |
Maximum Power | 1200W |
Fans Size | 135mm |
Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
Main Connector | 24Pin |
PCI-E Connectors | 6+2 Pin x 3 |
Modular | Fully Modular |
Efficiency | ≥90% Under Typical Load(50% Loading) |
Energy-Efficient | 80 Plus GOLD/Cybenetics_Platinum |
Over Voltage Protection | OCP / OVP / OPP / OTP / SCP / UVP |
Input Voltage | 100V – 240V~ |
Input Frequency Range | 50Hz – 60Hz |
Output | 1200W |
MTBF | 100,000 Hours |
Approvals | CE/FCC/CCC/TUV-RH/RCM/EAC/CAN,ICES-003 (B)/NMB-003(B)/UKCA/BIS/KC; |
Warranty | 10 Years |
Note** | **Prices, Specifications & Features are subject to change without notice. |
