COOLER MASTER MASTERWATT LITE 230V 700W POWER SUPPLY (MPX-7001-ACABW)
Lighten the Load
Power on. We want the MasterWatt Lite Series to be that simple. In the box are all the essentials of a reliable engine so you don’t have to think about it. We added higher-end perks like Active PFC and PWM technology for more stability, and made sure we met ErP 2013 and CE ratings for safety and low energy impact. It’s the survival kit for reliable, affordable power.
Advanced Circuit Design
Active PFC + PWM combined with dual forward topology and double EMI filter enhances power output efficiency and increases the performance and stability of your system
Silent and Durable Fan
Cooler Master’s 120mm HDB temperature control fan can operate more smoothly without friction, which makes it quiet and more durable.
Compliant with ErP 2013 Lot6, which guarantees that your PSU will use less than 1W on system standby and lower than 45% transferring efficiency on 5V standby.
Full protection (OCP/OVP/SCP/OPP) with built-in Over Temperature Protection (OTP). Minimizes the risk of damage from power outages.
|Product Name||MasterWatt Lite 230V (ErP 2013) 700W – Green power supply with ErP 2013 certified|
|Type||ATX 12V V2.31|
|Dimensions (LxWxH)||150mm x 140mm x 86mm|
|Fan Type||Silent 120mm HDB fan|
|PowerGood Signal||100-500 ms|
|Hold Up Time||>10ms at 100% full [email protected]|
|Protections||OCP / OVP / OPP / OTP / SCP|
|Connectors||MB 20+4 Pin||1|
|CPU 12V 4+4Pin||1|
|Peripheral 4 Pin||3|
|FDD Cable 4 Pin||1|
|PCI-e 6+2 Pin||4|
|Regulatory||TUV, CE, BSMI, FCC, cTUV-Rhus, KC, CCC, EAC, RCM|
|Note||***Features, Price and specifications are subject to change without notice.|
