COOLER MASTER MASTERWATT LITE 230V 700W POWER SUPPLY (MPX-7001-ACABW)

Description

COOLER MASTER MASTERWATT LITE 230V 700W POWER SUPPLY (MPX-7001-ACABW)

FEATURES

Lighten the Load

Power on. We want the MasterWatt Lite Series to be that simple. In the box are all the essentials of a reliable engine so you don’t have to think about it. We added higher-end perks like Active PFC and PWM technology for more stability, and made sure we met ErP 2013 and CE ratings for safety and low energy impact. It’s the survival kit for reliable, affordable power.

Advanced Circuit Design

Active PFC + PWM combined with dual forward topology and double EMI filter enhances power output efficiency and increases the performance and stability of your system

Silent and Durable Fan

Cooler Master’s 120mm HDB temperature control fan can operate more smoothly without friction, which makes it quiet and more durable.

Green Power

Compliant with ErP 2013 Lot6, which guarantees that your PSU will use less than 1W on system standby and lower than 45% transferring efficiency on 5V standby.

Safety Guardian

Full protection (OCP/OVP/SCP/OPP) with built-in Over Temperature Protection (OTP). Minimizes the risk of damage from power outages.

Product Name		MasterWatt Lite 230V (ErP 2013) 700W – Green power supply with ErP 2013 certified
Model number		MPX-7001-ACABW
Type		ATX 12V V2.31
PFC		Active PFC
Input Voltage		200-240Vac
Input Current		3.5-5A
Input Frequency		47-63Hz
Dimensions (LxWxH)		150mm x 140mm x 86mm
Fan Type		Silent 120mm HDB fan
PowerGood Signal		100-500 ms
Hold Up Time		>10ms at 100% full [email protected]
Efficiency		85% Typically
MTBF		>100,000 hours
Protections		OCP / OVP / OPP / OTP / SCP
Connectors	MB 20+4 Pin	1
	CPU 12V 4+4Pin	1
	SATA	6
	Peripheral 4 Pin	3
	FDD Cable 4 Pin	1
	PCI-e 6+2 Pin	4
Regulatory		TUV, CE, BSMI, FCC, cTUV-Rhus, KC, CCC, EAC, RCM
Warranty		5 Years
Note		***Features, Price and specifications are subject to change without notice.
