ARCTIC P12 PRESSURE OPTIMIZED 120MM CABINET FAN (ACFAN00118A)
OPTIMISED FOR STATIC PRESSURE
During the development of the new P12, special emphasis was placed on a focused airstream and thus a high static
pressure. The fan guarantees extremely efficient cooling, even with increased air resistance.
Therefore, the P12 is particularly suitable for use on heatsinks and radiators.
STRONG COOLING PERFORMANCE
Numerous improvements, such as an updated engine technology and a newly developed fan design, have noticeably increased the performance of P-fans.
In internal performance tests leveled to 28 dB (A), the new P-fans left many competitors behind.
HIGH QUALITY BEARING
Thanks to an alloy/lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development as well as less bearing noise, which means you can enjoy a longer service life from your fan.
TWO WAY INSTALLATION
|Fan Speed||1800 RPM|
|Airflow||56.3 CFM/ 95.7 m³/h|
|Static Pressure||2.20 mm H₂O|
|Noise Level||0.3 Sone|
|Operating Ambient Temperature||0 – 40 °C|
|Control Type||Fixed Speed|
|Connector||3 Pin Connector|
|Fan Bearing||Fluid Dynamic Bearing|
|Typical Voltage||12 V DC|
|Current / Voltage||0.20A / 12V|
|Size & Weight|
|Note**||**Prices, Features & Specifications are subject to change without notice|
