Description

Antec’s HCG M power supplies are the perfect combination of power and efficiency. The HCG M features special heavy-duty High Current connectors and cabling that supply extreme levels of power, and Active PFC. Highest-quality connectors, Japanese-brand capacitors, and a quiet 135 mm double ball bearing fan complete the package. The HCG-850M features High Current Cable Management and 10-pin modular connectors. If loads of power, High Current engineering and extreme efficiency are what you’re after, the HCG M is the PSU for you.

FEATURES
  • 850W Continuous Power – Guaranteed 850W of Continuous Power from Antec
  • 80 PLUS® BRONZE certified – Up to 88% efficient, to reduce your electricity bill
  • AQ5 – Antec Quality 5 year warranty and lifetime global 24/7 support
  • 16-pin Socket – Industry-leading 16-pin sockets double the modular connectivity by supporting 2 different 8-pin cables per socket and allow for future connector changes
  • 135 mm LED DBB Silence – Whisper-quiet high-quality LED double ball bearing fan with long lifetime
  • Thermal Manager – An advanced low voltage fan control for optimal heat & noise management
  • High Current Rails – 2 12V rails with high load capabilities ensure maximum CPU & GPU compatibility
  • 98.8% 12V – Output for maximum CPU & GPU support
  • Multi PCI-E – 4 PCI-E connectors for multiple GPU support
  • NVIDIA SLI®-Ready & AMD Crossfire certified – Tested & certified by NVIDIA® for SLI® & AMD for Crossfire systems
  • CircuitShield™ – Full suite of industrial grade protections:
    – Over Current Protection (OCP),
    – Over Voltage Protection (OVP),
    – Under Voltage Protection (UVP),
    – Short Circuit Protection (SCP),
    – Over Power Protection (OPP),
    – Over Temperature Protection (OTP) & Surge & Inrush Protection (SIP)
  • Japanese Heavy-Duty Caps – High-performance Japanese capacitors ensure tightest DC stability and regulation
  • Stealth Wires – All wires darkened for minimal visibility in chassis
PRODUCT SPECIFICATIONS
  • Model: HCG-850M
  • Series: High Current Gamer
  • Part Number: 0-761345-23893-9
  • Type: Power Supply
  • Compliant with: ATX12V 2.4 & EPS12V 2.92
  • Efficiency: 80 PLUS® BRONZE
  • Wattage: 850W
  • Input Voltage: 100VAC – 240VAC ~ ±10%
  • Input Current: 12A – 6A
  • Input Frequency: 50Hz – 60Hz
  • PFC: active
  • Operating Temperature: 0⁰C – 40⁰C
  • MTBF: ≥ 100,000 hours
  • Model: 3.4″ x 5.9″ x 6.7″ (HxWxD) / 86 mm x 150 mm x 170 mm HxWxD
  • Net Weight: 4.9lbs / 2.2 kg (without modular cables)
  • Unit Carton: 7.6″ x 12.2″ x 4.5″ (HxWxD) / 193 mm x 310 mm x 115 mm HxWxD
  • Gross Weight: 7.5lbs / 3.4 kg
