Description

Features

  • Supports AMD 3rd Gen Ryzen?/ 2nd Gen Ryzen?/ 2nd Gen Ryzen? with Radeon? Vega Graphics/ Ryzen? with Radeon? Vega Graphics Processors
  • Dual Channel ECC/ Non-ECC Unbuffered DDR4, 2 DIMMs
  • Direct 8 Phases IR Digital VRM Solution with PowIRstage
  • Advanced Thermal Design with Extended & Multi-Layered Heatsink
  • Dual Ultra-Fast?NVMe PCIe 4.0/3.0 x4 M.2 with?one Thermal Guard
  • Intel??WiFi 6 802.11ax 2T2R & BT 5
  • ALC1220-VB Enhance 114dB(Rear)/ 110dB(Front) SNR in Microphone with Nichicon Audio Capacitors
  • Intel??GbE LAN with cFosSpeed Internet
  • RGB FUSION 2.0 with Multi-Zone Addressable LED Light Show Design, Supports Addressable LED & RGB LED Strips
  • Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
  • Rear USB 3.1 Gen2 Type-C? Header & HDMI 2.0 support
  • Adopts a high quality ball bearing fan which guarantees 60,000 working hours.
  • Integrated Base Plate & I/O Shield Armor
  • Q-Flash Plus update BIOS without installing CPU, Memory and Graphics card
CPU AMD Socket AM4, support for: 3rd Generation AMD Ryzen? processors/ 2nd Generation AMD Ryzen? processors/ 2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/ AMD Ryzen? with Radeon? Vega Graphics processors(Please refer “CPU Support List” for more information.)
Chipset AMD X570
Memory 1. 3rd Generation AMD Ryzen? processors:
Support for DDR4 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
2. 2nd Generation AMD Ryzen? processors/2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/AMD Ryzen? with Radeon? Vega Graphics processors:
Support for DDR4 3600(O.C.) / 3400(O.C.) / 3333(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules
3. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
4. Dual channel memory architecture
5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*
* ECC mode supported by 3rd Gen AMD Ryzen?/ 2nd Gen AMD Ryzen? and only PRO sku of 2nd Gen AMD Ryzen? with Radeon? Vega Graphics processors/ AMD Ryzen? with Radeon? Vega Graphics processors.
6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
7. Support for Extreme Memory Profile (XMP) memory modules(Please refer “Memory Support List” for more information.)
Onboard Graphics Integrated Graphics Processor:

1 x DisplayPort, supporting a maximum resolution of 4096×2304@60 Hz
* Support for DisplayPort 1.2 version.
2 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
* Support for HDMI 2.0 version, HDCP 2.2, and HDR.

Support for up to 3 displays at the same time
Maximum shared memory of 16 GB

* For 2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/AMD Ryzen? with Radeon? Vega Graphics processors only.

Audio 1. Realtek? ALC1220-VB codec
* The back panel line out jack supports DSD audio.
2. High Definition Audio
3. 2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
LAN Intel? GbE LAN chip (10/100/1000 Mbit)
Wireless Communication Module 1. Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band
2. BLUETOOTH 5.0
3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots Integrated in the CPU (PCIEX16):

1. 3rd Generation AMD Ryzen? processors:
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
2.. 2nd Generation AMD Ryzen? processors:
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 (PCIEX16)
3. 2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/AMD Ryzen? with Radeon? Vega Graphics processors:
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 (PCIEX16)

Integrated in the Chipset:

1. 1 x M.2 Socket 1 connector for the wireless communication module (M2_WIFI)

Storage Interface Integrated in the CPU (M2A_SOCKET):

1. 3rd Generation AMD Ryzen? processors:
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 4.0 x4/x2 SSD support)
2. 2nd Generation AMD Ryzen? processors/2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/AMD Ryzen? with Radeon? Vega Graphics processors:
3. 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)

Integrated in the Chipset (M2B_SOCKET):

1. 1 x M.2 connector on the back of the motherboard (Socket 3, M key, type 2260/2280 SATA and PCIe 4.0* x4/x2 SSD support)
* For 3rd Generation AMD Ryzen? processors only.
2. 4 x SATA 6Gb/s connectors
3. Support for RAID 0, RAID 1, and RAID 10

Internal I/O Connectors 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x addressable LED strip header
1 x RGB LED strip header
4 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x speaker header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)
1 x Clear CMOS jumper
Back Panel Connectors 1 x DisplayPort
2 x HDMI ports
1 x USB 3.2 Gen 2 Type-A port (red)
4 x USB 3.2 Gen 1 ports
1 x USB Type-C? port, with USB 3.2 Gen 2 support
1 x Q-Flash Plus button
1 x RJ-45 port
2 x SMA antenna connectors (2T2R)
3 x audio jacks
Unique Features Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
AutoGreen
Cloud Station
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
RGB Fusion
Smart Backup
Smart Keyboard
Smart Survey
System Information Viewer
USB Blocker
Support for Q-Flash Plus
Support for Q-Flash
Support for Xpress Install
Operating System Support for Windows 10 64-bit
Form Factor Mini-ITX Form Factor; 17.0cm x 17.0cm
