Description
FEATURES
Behold the 80 Plus Gold rated, fully modular MWE Gold. This power supply unit delivers consistent 90% efficiency, low temperatures, and quiet operation. High quality, heat resistant components have been used to achieve gold level performance at temperatures up to 45°C. The Silencio fan and exclusive LDB bearing provides nearly silent cooling at no loss to system performance and a longer lifespan. Flat cables improve airflow by reducing cable bulk and a single 12V line ensures all components are fed the same stable output regardless of which cable you use. Be bold, power with gold
- 80 PLUS GOLD CERTIFIED: This certification guarantees a typical efficiency of 90% under normal operating conditions.
- FULLY MODULAR CABLES: Fully customizable cabling reduces clutter, increases airflow, and improves overall thermal performance.
- ADVANCED CIRCUITRY: The MWE Gold’s full-bridge design coupled with LLC, Synchronous, and DC to DC topology technologies offers reliable and stable voltage outputs.
- 5 YEAR WARRANTY: This unit comes with a standard limited manufacturing warranty of 5 years from the date of purchase.
- SEALED LDB FAN BEARING: The sealed LDB bearing has been combined with Silencio fan technology for quiet cooling with a longer lifespan.
- PSU Calculator: Need help choosing the right power supply for your system? Try out our easy to use, comprehensive PSU calculator.
PRODUCT SPECIFICATIONS
- Product Name: MWE Gold 750 Full Modular
- Product Number: MPY-7501-AFAAG
- ATX Version: ATX 12V V2.31
- PFC: Active PFC (>0.95 typical)
- Input Voltage: 100-240V
- Input Current: 12-6A
- Input Frequency: 50/60Hz
- Dimensions (LxBxH): 160 x 150 x 86mm
- Fan Size: 120mm
- Fan Bearing: LDB
- Powergood Signal: 100-500ms
- Hold Up Time: >14 ms @ 100% load
- Efficiency: 90% Typically
- ErP 2013 Lot 6: Yes
- MTBF: >100,000 Hours
- Operating Temperature: 0-45°C
- Protections: OVP / OPP / UVP / SCP / OTP
- Regulatory: CCC, CE, TUV-SUD, RCM, EAC, cTUVus, FCC, BSMI, KC, CB
- Connectors: MB 24 Pin: 1, CPU 12V 4 4 Pin: 1, SATA: 8, Peripheral 4 Pin: 6, FDD Cable 4 Pin: 1, PCI-e 6 2 Pin: 4
