Description
Nzxt H7 Flow Rgb Atx Mid Tower Cabinet Matte Black With Rgb Fans
The Nzxt H7 Flow Rgb revolutionizes GPU cooling in a classic mid-tower form factor. Its vertical PSU layout allows space for 3 x 120mm bottom fans, offering efficient cooling without expanding the case footprint.
- Supports three bottom-mounted 120mm fans for direct GPU cooling while retaining a narrow mid-tower footprint.
- Comes equipped with a F360 RGB Core single-frame fan for exceptional out-of-the-box cooling and RGB lighting.
- High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.
- Supports up to 420mm radiators in the front and 360mm radiators in the top for powerful cooling potential.
- Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.
- Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.
- Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.
- Tool-less access to the front, top, and side panels makes building and upgrading a breeze.
Key Specs | |
Motherboard Support | E-ATX (Up to 27.7mm), ATX, Micro-ATX, Mini-ITX |
Enclosure Type | Mid-Tower |
Case Material | SGCC Steel, Ultra-Clear Tempered Glass (White) |
Dimensions | |
Height (With Feet) | 544mm |
Width | 244mm |
Depth | 468mm |
Weight | 11.13 Kg |
Compatiblity & Clearance | |
CPU Cooler Height | Up to 185mm |
GPU Length | Up to 410mm |
PSU Length | Up to 200 mm |
Cable Management | Up to 34.5 mm |
Top Mounted 140mm / 280mm Radiator & Fan Combined Thickness | Up to 57 mm |
Front I/O Ports | |
USB 3.2 Gen 1 Type-A | 2 |
USB 3.2 Gen 2 Type-C | 1 |
Headset Audio Jack | 1 |
Expansion Slots | |
Standard | 7 |
Vertical | 0 |
Drive Bays | |
2.5″ | 2+2 |
3.5″ | 2 |
Fan Support | |
Front | 3 x 120 mm / 3 x 140 mm (1 x F360 RGB Core included) |
Top | 3 x 120 mm / 2 x 140 mm |
Bottom | 3 x 120 mm |
Rear | 1 x 120 mm / 1 x 140 mm |
Filters | High-Performance Mesh |
Radiator Support | |
Front | Up to 420 mm |
Top Rear | Up to 360mm |
Rear | Up to 140mm |
Fan Specs | |
Model | F360 RGB Core Fan (Case Version) |
Speed | 1,700 ± 200 RPM |
Airflow | 50.1 CFM |
Static | 1.27 mm-H₂O |
Noise | 23.3 dBA |
Fan Connector | 3-pin |
Warranty | 2 Years |
Note** | **Prices, Specifications & Features are subject to change without notice |
