Description

Features

AMD X570 UD Motherboard with 10+2 Phases Digital VRM, Advanced Thermal Design with Enlarge Heatsink, PCIe 4.0 x4 M.2 Connector, PCIe 4.0 x16 Slot Armor with Ultra Durable? Design, GIGABYTE Gaming GbE LAN with Bandwidth Management, HDMI 2.0

  • Supports AMD 3rd Gen Ryzen?/ 2nd Gen Ryzen?/ 2nd Gen Ryzen? with Radeon? Vega Graphics/ Ryzen? with Radeon? Vega Graphics Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • 10+2 Phases Digital VRM Solution
  • Advanced Thermal Design with Enlarge Heatsink
  • Ultra-Fast?NVMe PCIe 4.0/3.0 x4 M.2 Connector
  • High Quality Audio Capacitors and Audio Noise Guard for Ultimate Audio Quality
  • GIGABYTE Gaming GbE LAN with Bandwidth Management
  • Supports RGB Light Strip in Full Colors
  • Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
  • Featured HDMI 2.0 support
  • Q-Flash Plus update BIOS without installing CPU, Memory and Graphics card

Specifications

CPUAMD Socket AM4, support for: 3rd Generation AMD Ryzen? processors/ 2nd Generation AMD Ryzen? processors/ 2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/ AMD Ryzen? with Radeon? Vega Graphics processors (Please refer “CPU Support List” for more information.)
ChipsetAMD X570
Memory
  1. 3rd Generation AMD Ryzen? processors:
    Support for DDR4 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
  2. 2nd Generation AMD Ryzen? processors/2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/AMD Ryzen? with Radeon? Vega Graphics processors:
    Support for DDR4 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules
  3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
  4. Dual channel memory architecture
  5. Support for ECC Un-buffered?DIMM 1Rx8/2Rx8 memory modules*
    * ECC mode supported by 3rd Gen AMD Ryzen?/ 2nd Gen AMD Ryzen? and only PRO sku of 2nd Gen AMD Ryzen? with Radeon? Vega Graphics processors/ AMD Ryzen? with Radeon? Vega Graphics processors.
  6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  7. Support for Extreme Memory Profile (XMP) memory modules

(Please refer “Memory Support List” for more information.)

Onboard GraphicsIntegrated Graphics Processor:

  1. 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
    * Support for HDMI 2.0 version, HDCP 2.2, and HDR.

Maximum shared memory of 16 GB

Note: For 2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/AMD Ryzen? with Radeon? Vega Graphics processors only.

Audio
  1. Realtek??ALC887 codec
  2. High Definition Audio
  3. 2/4/5.1-channel
LANRealtek??GbE LAN chip (10/100/1000 Mbit)
Expansion SlotsIntegrated in the CPU:
? 3rd Generation AMD Ryzen? processors:

  1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support)

? 2nd Generation AMD Ryzen? processors/2nd Generation AMD Ryzen? with Radeon? Vega Graphics processors/AMD Ryzen? with Radeon? Vega Graphics processors:

  1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support)

Integrated in the Chipset:

  1. 6 x SATA 6Gb/s connectors
  2. Support for RAID 0, RAID 1, and RAID 10
USBIntegrated in the CPU:

  1. 4 x USB 3.2 Gen 1 ports on the back panel

Chipset:

  1. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
  2. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 8-pin ATX 12V power connector
  3. 1 x CPU fan header
  4. 1 x water cooling CPU fan header
  5. 2 x system fan headers
  6. 1 x RGB LED strip header
  7. 6 x SATA 6Gb/s connectors
  8. 1 x M.2 Socket 3 connector
  9. 1 x front panel header
  10. 1 x front panel audio header
  11. 2 x USB 3.2 Gen 1 headers
  12. 2 x USB 2.0/1.1 headers
  13. 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)
  14. 1 x Clear CMOS jumper
Back Panel Connectors
  1. 1 x PS/2 keyboard/mouse port
  2. 1 x HDMI port
  3. 4 x USB 3.2 Gen 1 ports
  4. 2 x USB 2.0/1.1 ports
  5. 1 x Q-Flash Plus button
  6. 1 x RJ-45 port
  7. 3 x audio jacks
I/O ControlleriTE??I/O Controller Chip
H/W Monitoring
  1. Voltage detection
  2. Temperature detection
  3. Fan speed detection
  4. Water cooling flow rate detection
  5. Overheating warning
  6. Fan fail warning
  7. Fan speed control
    * Whether the fan speed control function is supported will depend on the fan you install.
BIOS
  1. 1 x 128 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
  1. Support for APP Center
    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    @BIOS
    Ambient LED
    AutoGreen
    Cloud Station
    EasyTune
    Fast Boot
    Game Boost
    ON/OFF Charge
    Smart Backup
    Smart Keyboard
    Smart Survey
    System Information Viewer
    USB Blocker
  2. Support for Q-Flash Plus
  3. Support for Q-Flash
  4. Support for Xpress Install
Bundled Software
  1. Norton??Internet Security (OEM version)
  2. Realtek??8118 Gaming LAN Bandwidth Control Utility
Operating SystemSupport for Windows 10 64-bit
Form FactorATX Form Factor; 30.5cm x 24.4cm
Warranty3 Years
Note***Features, Price and Specifications are subject to change without notice.
