COOLER MASTER MASTERBOX NR600 WITH ODD ATX MID TOWER CABINET (MCB-NR600-KG5N-S00)
Form & Function Steamlined
The MasterBox NR600 is a pure and simple design that is focused on airflow performance. A single-layer, fine mesh makes up the entire front panel, achieving efficient airflow while also acting as a dust filter.
Seamless Tempered Glass
The tempered glass side panel sits completely flush against the chassis, mounted securely and discreetly by a system of tabs and thumbscrews.
Ample Storage Support
A total of 5 x 2.5″ and 4 x 3.5″ drives can be mounted using a tool-less system. Storage can be mounted on the PSU shroud, behind the motherboard tray, and in the HDD cage.
The single 4 pole headset jack features both Audio and Microphone capabilities simultaneously so that separate jacks are not needed.
Front: 140mm x2 / 120mm x3
Top: 140mm x2 / 120mm x2
Rear: 120mm x1
|Pre-Installed Fans||PRE-INSTALLED FANS – FRONT = 120mm x 1 PRE-INSTALLED FANS – REAR = 120mm x 1 FAN SUPPORT – TOP = 140mm x 2, 120mm x 2 FAN SUPPORT – REAR = 120mm x 1|
|Radiator Support||RADIATOR SUPPORT – FRONT = 280mm, 240mm, 140mm, 120mm RADIATOR SUPPORT – TOP = 240mm (w/ ODD removed) RADIATOR SUPPORT – REAR = 120mm|
|Cable Routing||CABLE ROUTING – BEHIND MOTHERBOARD TRAY = 20-28mm / 0.78-1.10″|
|Clearances||CLEARANCE – CPU COOLER = 166mm / 6.54″ CLEARANCE – PSU = 180mm/7.08″ CLEARANCE – GPU = 410mm / 16.14″|
|Dust Filters||Top, Bottom|
|Material||MATERIALS – BODY = Steel, Plastic MATERIALS – SIDE PANEL = Tempered Glass|
|Drive Bays||5.25″ DRIVE BAYS = 1 3.5″ DRIVE BAYS = 4 2.5″ DRIVE BAYS = 5|
|Motherboard Support||ATX, Micro ATX, Mini ITX|
|Dimensions||478 (L) x 209 (W) x 473 (H) mm|
|I/O Panel||2x USB 3.0, 1x 3.5mm Headset Jack (Audio+Mic)|
|Power Supply||POWER SUPPLY SUPPORT = Bottom Mount, ATX|
|Note*||Price, feature and specifications are subject to change without notice.|
