Cooler Master Masterbox Mb510L Cabinet

Model No : MCB-B510L-KANN-S00


Inclusive of all taxes

  • Carbon Texture
  • Aggressive Intakes
  • Edge-To-Edge Transparent Side Panel
  • Support for a Total of 6 Fans and Water Cooling
  • Graphics Card Support Up to 400mm
  • Multiple Trim Colors Available
all india shipping
3 day replacement
secured shopping
genuine products
no hidden charges
competitive pricing

Out of stock


  • CARBON TEXTURE: Racing and motorsports act as an inspiration for the carbon texture design.
  • AGGRESSIVE INTAKES: Large intakes on each side of the front panel pay tribute to high performance cars.
  • THERMAL PERFORMANCE: Optimized airflow due to the large intakes on each side of front panel and ventilation holes on top of the case.
  • FAN AND RADIATOR SUPPORT: Front: Three 120mm or two 140mm fans and up to a 360mm radiator with a maximum thickness of 50mm without fans.
    Top: Two 120mm or two 140mm fans and supports a 120mm or a 240mm radiator.
    Rear: One 120mm fan or radiator. All to ensure you don’t have to compromise on performance.
  • EDGE-TO-EDGE TRANSPARENT SIDE PANEL: Showcase your build through the transparent side panel.
  • EXPANDING THE POSSIBILITIES: The spacious interior fits all standard motherboards for your gaming needs. ATX, MICRO-ATX, MINI-ITX
  • MAIN COMPONENTS CLEARANCE: The MB510L case supports CPU Coolers up to a height of 165mm, Graphic cards up to a length of 410mm and Power Supplies up to a length of 180mm.
  • Product Name: MasterBox MB510L
  • Model number: MCB-B510L-KANN-S00(Red)
  • Materials: Steel, Plastic
  • Dimensions (L x W x H): 496 x 217 x 468 mm
  • Motherboard Support: ATX ( up to 272mm width), Micro-ATX, Mini-ITX
  • Expansion Slots: 7
  • 5.25″ Drive Bays: No
  • Combo 3.5″/2.5″ Drive Bays: 2 (Max. 2)
  • SSD Drive Bays: 4 (Max. 6)
  • I/O Panel: USB 3.0 x 2, Audio In / Out
  • Pre-installed Fan(s): Rear: 120mm x 1
  • Fan Support: Top: 120mm x 2 / 140mm x 2, Front: 120mm x 3 / 140mm x 2, Rear: 120mm x 1
  • Liquid Cooling Support: Front: 120 / 140 / 240 / 280 / 360mm (75mm clearance), Top: 120 / 240mm, Rear: 120mm
  • Clearances: CPU Cooler: 165mm / 6.49″
  • PSU: 180mm / 7.08″
  • GFX: 410mm / 16.10″
  • Cable Routing: Behind MB Tray: 19mm / 0.74″
  • Dust Filters: Front, Bottom
  • Power Supply Support: Bottom mount, ATX
  • Carton Dimension (L x W x H): 52.3 x 27.6 x 56.8 cm
