Model |
MPW-7001-ACAAG |
ATX Version |
ATX 12V V2.52 |
PFC |
Active PFC |
Input Voltage |
100-240V |
Input Current |
10-5A |
Input Frequency |
47-63Hz |
Dimensions |
140 x 150 x 86 mm |
Fan Size |
120mm |
Fan Bearing |
HDB |
Efficiency |
≥90% @ Typical Load |
80 Plus Rating |
80 PLUS Gold |
ERP 2014 LOT 3 |
Yes |
Operating Temperature |
0-40°C |
Power Good Signal |
100 – 150 ms |
Hold Up Time |
≥15ms at 100% load |
MTBF |
>100,000 Hours |
Protections |
OVP, UVP, OPP, OTP, SCP, OCP |
Regulatory |
CB, cTUVus, TUV, CE, RoHS2.0, FCC, CCC, BSMI, KC+KCC, BIS, EAC |
ATX 24 Pin Connectors |
1 |
EPS 4+4 Pin Connectors |
1 |
EPS 8 Pin Connector |
1 |
SATA Connectors |
6 |
Peripheral 4 Pin Connectors |
3 |
PCI-E 6+2 Pin Connectors |
4 |
Series |
G Series |
80 Plus |
Gold |
Modular |
Non-Modular |
Wattage |
500 to 750W |
Warranty |
5 Years |
Note** |
***Prices, Features & Specifications are subject to change without notice |
