Antec Hcg-850 Smps – 850 Watt 80 Plus Gold Certification Fully Modular Psu With Active Pfc

Description

PRODUCT SPECIFICATIONS

• Model: HCG 850 GOLD
• Type: ATX 12V 2.4
• Modular: Fully Modular
• Dimension (W x L x H): 140(L)*150(W)*86(H) mm
• Warranty: 10 Years
• Input Voltage: 100-240 vac ± 10%
• Input Current: 12A-6A
• Input Frequency Range: 50Hz-60Hz
• PFC: Active PFC (>0.9 typical)
• Power Good signal: 100-500ms
• Efficiency: 92% Typically
• Protection: OCP/OVP/UVP/SCP/OPP/OTP/SIP/NLO
• Output Capacity: 850W
• Operation Temperature: 0 ˜ 40°c
• Regulatory: cTUVus/TUV/CB/RCM/CE/EAC/CCC/BSMI/FCC/KR
• Fan: 120mm FDB Fan
• Certification: 80 Plus Gold
• Connector: 1 x MB 24(20 4) Pin, 2 x 8 (4 4) Pin EPS 12V, 6 x 8(6 2) Pin PCI-E, 10x SATA, 5 x Molex, 1 x FDD
• Net Weight: 2.46 kg
• Gross Weight: 3.77 kg
